Class | Propeller | Engine | Description | OEM Part No. | Blds | Remarks |
A |  | 8 ~ 15 HP 13 tooth spline | J15 9 1/2 X 10 | 778772 | 3 | Rubber Bushing |
B |  | 15 ~ 35 HP 14 tooth spline | J25 10 X 13 | 778863 | 3 | Rubber Bushing |
J25 10 X 15 | 763486 | |||||
C |   | 40 ~ 50 HP 13 tooth spline | U40 12 1/4 X 9 | 3 | Interchangeable Hub Kit BH-SJC | |
U40 11 3/4 X 10 | ||||||
U40 11 5/8 X 11 | ||||||
U40 11 3/8 X 12 | ||||||
U40 11 1/8 X 13 | ||||||
U40 11 1/4 X 14 | ||||||
4U40 10 5/8 X 12 | 48-8M8026625 | 4 | ||||
4U40 10 3/8 X 13 | 48-8M8026630 | |||||
4U40 10 1/8 X 14 | 48-8M8026635 | |||||
4U40 10 1/8 X 15 | 48-8M8026640 | |||||
Suzuki C propeller can also be used. | 3 | Rubber Bushing | ||||
 | 40 ~ 75 HP 13 tooth spline | J48 12 1/2 X 13 | 763461 | 3 | Rubber Bushing | |
| J48 12 1/4 X 15 | 778774 | |||||
U48 12 1/2 X 13 | 3 | Interchangeable Hub Kit BH-JC48 | ||||
U48 12 1/4 X 15 | ||||||
D |  | 45 ~ 140 HP 13 tooth spline | J70 14 X 13 | 391668 | 3 | Rubber Bushing |
J70 13 3/4 X 15 | 391198 | |||||
J70 13 1/4 X 17 | 763463 | |||||
J70 14 X 17 | 176214 | |||||
J70 13 1/4 X 19 | 763464 | |||||
E |    | 90 ~ 300 HP 15 tooth spline | J150 15 1/2 X 13 | 763453 | 3 | Rubber Bushing |
J150 15 1/2 X 15 | 391535 | |||||
J150 15 X 17 | 391200 | |||||
U150 15 1/4 X 15 | 48-78116A45 | 3 | Interchangeable Hub Kit BH-JE ** U150 16 X 13 and U150 16 X 16 cannot be used for Evinrude E class because the diameter is more than 16 inch. | |||
| U135 15 X 17 | 48-832828A45 | |||||
| U150 14 1/2 X 19 | 48-832830A45 | |||||
| U150 14 1/4 X 21 | 48-832832A45 | |||||
U150 14 X 23 | 48-832834A45 | |||||
| 4U150 15 X 16 | 48-834850A45 | 4 | ||||
| 4U150 14 1/2 X 18 | 48-834852A45 | |||||
4U150 14 X 20 | 48-834854A45 | |||||
